Dell Latitude 15 Intel Core i5-1235U (16 GB/512 GB) Model: 3540
Key Details for Dell Latitude 15 Intel Core i5-1235U (16 GB/512 GB) Model: 3540 onn002l3540063in9
Related Laptop
Top 10 Laptops
Specification of Dell Latitude 15 Intel Core i5-1235U (16 GB/512 GB) Model: 3540 onn002l3540063in9
General | |
|---|---|
Brand | Dell |
Series?A manufacturer's specific line of laptops, such as Apple MacBook, Dell XPS, or Lenovo Legion. These series are designed with distinct features and target specific user needs, like portability, performance, or gaming. | Dell Latitude |
Model Name? The specific version or product designation of a laptop computer. It typically includes the manufacturer's name followed by a model number or name (e.g., Dell XPS 13, MacBook Pro, HP Spectre x360). The model helps identify the exact configuration, design, and feature set of the laptop. | Dell Latitude 15 (3540) |
Segment?A classification category for laptops based on intended use, price range, and target audience (e.g., budget, business, gaming, premium, ultraportable). | Productivity |
Variant Name?The specific version or configuration of a laptop model, often indicating differences in components, colors, or features while being part of the same product line. | Dell Latitude 15 Intel Core i5-1235U (16 GB/512 GB) Model: 3540 onn002l3540063in9 |
Part Name?A unique alphanumeric code assigned to a specific component or device model. It's used for inventory tracking, ordering, and identifying exact specifications for repairs or replacements. | onn002l3540063in9 |
Processor?The central processing unit (CPU), the core component that executes instructions and performs calculations. Its speed and core count significantly impact a computer's overall performance and responsiveness. | Intel Core i5 1235U Processor |
Dimension (W X D X H) mm | 359 X239.7 X20.4 mm |
Color | Grey |
Launch Date | May 2023 |
Display Details | |
|---|---|
Display Size | 15.6" |
Resolution?The number of pixels displayed on the screen, expressed as width x height (e.g., 1920x1080). Higher resolution results in sharper, more detailed images. | 1920 x 1080 |
Brightness?The intensity of light emitted by the display, measured in nits. Higher brightness improves visibility in well-lit environments and outdoor use. | 250 Nits |
Refresh Rate?The number of times the display updates the image per second, measured in Hertz (Hz). A higher refresh rate provides smoother motion, especially for gaming and video playback. | 60 Hz |
Technology?The type of panel used in the display, such as IPS, OLED, or TN. Each technology offers different characteristics in terms of color accuracy, viewing angles, and response times. | IPS |
Touch Screen | No |
Wide Screen?Indicates a display with an aspect ratio wider than the traditional 4:3, typically 16:9 or 16:10. Wide screens are better suited for multimedia consumption and multitasking. | 16:10 |
Color Gamut?The range of colors a display can reproduce. A wider color gamut results in more vibrant and accurate colors, crucial for creative professionals and media enthusiasts. | 45% NTSC |
Features | Anti-glare |
Processor | |
|---|---|
Processor?The central processing unit (CPU), the core component that executes instructions and performs calculations. Its speed and core count significantly impact a computer's overall performance and responsiveness. | Intel Core i5 1235U Processor |
Instruction Set?The set of commands that a processor understands and can execute. Different instruction sets support varying levels of performance and compatibility with software. | X86 |
Frequency?The standard operating speed of the processor cores, measured in gigahertz (GHz). It indicates the processor's baseline performance level. | 1.3 Ghz |
Boost Frequency?The maximum speed a processor core can reach under heavy load, measured in gigahertz (GHz). It represents the processor's peak performance capability. | 4.4 Ghz |
Number of Core?The number of independent processing units within a CPU. More cores allow the processor to handle multiple tasks simultaneously, improving multitasking performance. | 10 |
Number of Threads?The number of virtual processing units a CPU can handle simultaneously. Threads enable a single core to process multiple instruction streams, enhancing efficiency. | 12 |
IGPU?Integrated Graphics Processing Unit (IGPU) is a graphics processor built into the CPU. It handles basic graphics tasks, reducing the need for a dedicated graphics card. | Intel Iris Xe Graphics eligible |
IGPU Shading Units?The number of processing units within the IGPU responsible for rendering graphics. More shading units generally result in better graphics performance. | 640 |
IGPU Perfomance?The overall graphics processing capability of the integrated GPU. This is measured by how well it can handle graphical tasks, such as video playback and light gaming. | 1.5 TFLOPS |
NPU?Neural Processing Unit (NPU) is a specialized processor designed to accelerate artificial intelligence and machine learning tasks. | Intel AI Boost |
Memory | |
|---|---|
Ram?Random Access Memory (RAM) is the computer's short-term memory, used to store data and instructions that the processor needs quickly. | 16 GB |
Type?The generation of RAM, such as DDR4 or DDR5. Newer RAM types offer faster speeds and improved efficiency. | DDR4 |
Speed?The data transfer rate of the RAM, measured in megahertz (MHz). Higher speeds result in faster data access and improved performance. | 3200 MHz |
Ram Slots?The number of physical slots available on the motherboard for installing RAM modules. More slots allow for greater RAM capacity. | 2 |
Max Ram Supported?The maximum amount of RAM that the motherboard and processor can support. This limits the total RAM capacity of the computer. | 64 GB, DDR4, 3200 MT/s |
Storage | |
|---|---|
Storage?The device used to store data permanently, such as files, applications, and the operating system. Storage capacity is measured in gigabytes (GB) or terabytes (TB). | 512 GB |
Storage Type?The technology used for storage, such as SSD (Solid State Drive) or HDD (Hard Disk Drive). SSDs offer faster speeds and better performance compared to HDDs. | SSD |
Storage Gen?The specific generation or interface of the storage device, indicating its speed and capabilities (e.g., PCIe 3.0, PCIe 4.0, SATA III). Newer generations offer faster data transfer rates. | M.2 2230 solid state drive |
Multimedia | |
|---|---|
Camera | 1080P FHD |
Camera Features | HDR RGB Camera, TNR, Camera Shutter |
Mic | Digital-array microphones |
Speakers | 2 W x 2 = 4 W |
Audio Features | Realtek ALC3204 |
Wireless | |
|---|---|
WLan | Intel Wi-Fi 6E AX211, 2x2, 802.11ax, Bluetooth 5.3 wireless card |
Wlan Gen?The generation of Wi-Fi technology supported by the device, such as Wi-Fi 6 or Wi-Fi 7. Newer generations offer faster speeds, improved reliability, and better performance in crowded networks. | 6 |
Bluetoth | Bluetooth 5.3 |
Bluetoth Gen?The generation of Bluetooth technology supported by the device, such as Bluetooth 5.2 or Bluetooth 5.3. Newer generations offer faster data transfer rates, improved range, and lower power consumption. | 5.3 |
Ports | |
|---|---|
Ports | 1 Flip-down RJ 45 10/100/1000 Mbps 1 USB 3.2 Gen 2 Type-C port with Power Delivery and DisplayPort 1.4 Alt mode 1 USB 3.2 Gen 1 port with PowerShare 2 USB 3.2 Gen 1 port 1 universal audio port 1 HDMI 1.4 port |
Input Device | |
|---|---|
Input | Keyboard, Touchpad |
Numeric Keyboard | Yes |
Keyboard Backlight | No |
Finger Print Reader | No |
Card Reader | No |
Features | Single Pointing Non-Backlit US International Keyboard with numeric keypad |
Battery & Power | |
|---|---|
Battery Capacity | 42 Whr |
Battery Technology | Lithium Polymer |
Charger Output | 65W |
Software | |
|---|---|
Operating System | Windows 11 Pro |
Other Details | |
|---|---|
Included Accessories | 65W AC rugged adapter |
Security Features | TPM 2.0 discrete |
Product Link | Dell |
Dell Latitude 15 Intel Core i5-1235U (16GB/512GB) Model 3540: Specs and Use Cases
The Dell Latitude 15 Model 3540 offers a balance of performance, reliability, and portability. Designed for professionals, students, and casual users, this laptop ensures smooth multitasking and versatile functionality.
Key Specifications
Processor: Intel Core i5-1235U
Codename: Alder Lake
Core Structure:
- P-Cores: 2 (Base Frequency: 1.3 GHz, Boost Frequency: 4.4 GHz)
- E-Cores: 8 (Base Frequency: 0.9 GHz, Boost Frequency: 3.3 GHz)
- Manufacturing Technology: 10 nm
This hybrid 10-core processor delivers efficient multitasking, responsive performance, and energy-saving operations, making it ideal for professional workloads and everyday tasks.
Integrated Graphics: Intel Iris Xe Graphics
- Base/Boost Frequency: 300 MHz/1.20 GHz
- Shading Units: 640
- Performance Power: 1.5 TFLOPS
The Iris Xe Graphics provides crisp visuals and supports light creative tasks, presentations, and media playback.
Neural Processing Unit (NPU): Intel AI Boost AI-enhanced capabilities optimize multitasking, streamline applications, and improve workflows for efficient productivity.
Display
- Screen Size: 15.6 inches
- Resolution: 1920 x 1080 (FHD)
- Refresh Rate: 60 Hz
- Brightness: 250 Nits
- Color Gamut: 45% NTSC
The large FHD display offers clear visuals and vibrant colors, making it suitable for video conferencing, content creation, and entertainment.
Storage and Memory
Storage: 512GB SSD (M.2 PCIe NVMe)
The high-speed SSD ensures quick boot-ups, fast file access, and sufficient storage for essential software, multimedia, and professional documents.
RAM: 16GB DDR4 (3200 MHz)
Reliable DDR4 memory supports seamless multitasking, fast data processing, and consistent performance for light-to-moderate workloads.
Connectivity
Wireless Features:
- Wi-Fi Version: 6
- Bluetooth: 5.3
Modern connectivity ensures efficient collaboration, low-latency streaming, and easy pairing with external peripherals.
Audio and Camera
Audio Features:
- Realtek ALC3204 delivers clear and immersive sound quality, enhancing virtual meetings, media playback, and casual entertainment.
Camera:
- Resolution: 1080P FHD
The high-definition camera ensures sharp visuals for video conferencing, online learning, and remote collaboration.
Battery and Power
- Battery Capacity: 42 Whr
- Charger Output: 65W
The efficient battery provides moderate usage throughout the day, while the reliable charger restores power quickly for uninterrupted workflows.
Use Cases
For Professionals:
The responsive processor, sharp display, and ample storage make this laptop perfect for managing workflows, multitasking, and preparing presentations.
For Students:
Portable and dependable, the Latitude 15 supports online learning, collaborative group projects, and research tasks seamlessly.
For Multitaskers:
With robust internals and efficient storage, this laptop handles multiple applications, ensuring smooth transitions and consistent performance.
For Casual Users:
The immersive visuals, high-quality audio, and reliable functionality make it excellent for streaming, browsing, and casual productivity tasks.
